CPU
|
– INTEL® Bay Trail J1900 (2.0GHz) Quad Core processor
– 2 Phase CPU Power Support
|
|
Chipset
|
– Fintek® F71869A
|
|
Memory
|
– 1*SO-DIMM slot
– Support DDR3L 1333
– Max. capacity of system memory up to 8GB
|
|
Expansion Slots
|
– 1 * MiniPCI-E connector
– 1* PCIex1 slot
|
|
Storage
|
– 1* Serial ATA2 3Gb/s connector
– 1 * M-SATA Connector
|
|
Audio
|
– !!! No Sound Support !!!
|
|
Ethernet LAN
|
– 2*Realtek® RTL8111H Chip
– PCI Express Gigabit LAN
|
|
LVDS
|
– !!! No LVDS Support !!!
|
|
USB
|
– 3* USB 2.0/1.1
– 1* USB3.0
|
|
Special Features
|
– Support CPU Smart Fan
– Support Watch dog Technology
– Support GPIO Technology
– Support Power On board
– Support Slim Fan design
– Support Slim hard drive design
– Thunder Protection Function
– All Solid Capacitor design
– All Power Pack MOSFET design
|
|
Back Panel I / O
|
– 3* USB 2.0/1.1 ports
– 1* USB3.0 port
– 2* RJ-45 port
– 1* Line-out port
– 1* VGA port (Max. Resolution: 1920*1080@60Hz)
– 1* COM port
– 1* LPT port
|
|
Internal I / O
|
– 2* CPU / Chassis Fan connectors
– 1* PS2/KB header
– 1* 4-pin ATX 12V Power connector
– 1* 4-pin SATA Power connector
– 1* GPIO header
– 1* Mini PCI-e connector
– 1* M-SATA Connector
– 1* SATA Connector
– 1* Front panel header
|
|
BIOS
|
– AMI 64MB DIP Flash ROM
|
|
Temperature
|
– Operating: 0°C ~ 60°C
– Storage: -20°C ~ 85°C
|
|
Form Factor
|
-Thin mini ITX Form Factor (170mm X 170mm)
|
